Fertilizer Spreader ECOTOP 300
Request information →Need a different configuration? We also build made-to-measure versions. Ask for a dedicated solution
DESCRIPTION
ECOTOP 300 mounted fertilizer spreader with double cone-shaped hopper and spreading disc.
TECHNICAL CHARACTERISTICS
- Light single-tube frame, painted blue
- Hot-dip galvanized double cone-shaped hopper with 2 adjustable outlet holes
- Imported aluminium gearbox with lubricated gears
- Spreading disc with 4 adjustable vanes
- Standard cast-iron agitator
- Manual lever to open the metering device
- CE use and maintenance manual
ACCESSORIES ON REQUEST
- Articulated agitator for powdery fertilizers
- Hot-dip galvanized closed side conveyor
- AISI 304 stainless steel closed side conveyor
- Cardan shaft L = 700 mm
- Hot-dip galvanized closed bilateral conveyor (with 4-hole hopper)
- AISI 304 stainless steel closed bilateral conveyor (with 4-hole hopper)
- Manual shutter for the bilateral conveyor (to fertilize 1 row)
- Hot-dip galvanized spreading limiter
- Flex cable for remote control
- Hydraulic opening
- AISI 304 stainless steel disc and vanes
- 3 castor wheels to move the spreader in the warehouse
- Cover tarpaulin
Technical data
| Technical data | ECOTOP 300 |
|---|---|
| Hopper capacity (litres) | 270 |
| Spreading width (metres) | 6÷14 |
| Dimensions (cm) | Ø 110 x 89 |
| Empty weight (kg) | 58 |
| Spreading capacity (hectares/hour) | 3,5 |
| Minimum tractor power (HP) | 20 |
| Power take-off (rpm) | 540 |
| Fertilizer to be distributed | Granular chemical, powdery, pelleted |
